- RCM Multipurpose can be used as a tile backer board.
- RCM Multipurpose can be used in internal and external walling.
- RCM Multipurpose can be used in Facia’s and soffit liner.
- OEM applications for improved strength and density.
Key Applications
- Internal and external walling
- Facia’s and soffit liner
- OEM applications for improved strength and density
- Tile backer board
Key Features
- Fire rated to EN 13501-1 class A1 non-combustible
- Exceptional racking strength EN 594:2011
- High impact resistance
- BBA Approved
- Excellent weathering properties
- Wide range of thicknesses
- Extensive range of applications
- Range of soffit strips available
- Integrates with other RCM products
Workability
RCM Multipurpose can be cut, drilled and nailed with conventional woodworking tools.
For cutting the product in any volume, we recommend the use of an RCM polycrystalline diamond Dart Blade to avoid excessive wear on other blades. Alternatively, RCM offer a complete fabrication service, please contact our technical department for details or visit the fabrication and design page here.
Suitable for the Following Construction Types
Lightweight Steel Frame
Timber Frame
Modular / Offsite
Concrete Frame
Technical Request Form
For Technical Service or Product Support please file a technical request using our support form or contact your local representative.
Technical Request FormContact Us
Can’t find the solution you’re looking for? We can help. Our team of experts are on hand to answer your questions.
Contact UsA building board with multiple uses
Multipurpose
Technical Data
Nominal Density
1375 kg/m3
Bending Strength
((Modulus of Rupture))937 N/mm2
Thermal Conductivity
0.12 W/mk
Moisture Content
≤8%
Reaction to Fire
BS EN 13501-1 Class A1 Non Combustible
Biological Resistance
Highly Resistant
Surface Condition
Front Face - Smooth
Back Face - Textured
Durability
((Life Expectancy - Minimum))30 years
Standard Board Sizes
2400 x 1200mm
Thickness
((mm))3.2 4.5 6 9 12
Nominal Mass of Product
((kg/m²))6.2 8.25 12.4 16.5
Dimensional Tolerance
Length
+1/-2mm
Width
+1/-2mm
Thickness
±10%
Product Testing and Certification
Fire Reaction Tests
BS EN 13501-1 Class A1 Non-Combustible
Category 1 fire rated through wall solution to BS 476 part 21 and BS 476 part 22.
BS EN 1364-1
BS EN1365-1
BS EN ISO 1716:2018
BS EN ISO 1182:2020
Physical Properties
EN ISO 12467
EN 594:2011 and BS 5268-6.1¹
Recommended Fixings
Steel Frame
4.8mm x 38mm Wing tip self drilling fixing
Timber Frame
4.2mm x 42mm Climaseal self drilling fixing
Further Information
Soffit Strips Available
FAQ's
RCM Multipurpose has one smooth face and one textured face, the smooth face should be fixed outermost.
RCM Multipurpose has a rating of A1 to EN13501-1 this is a reaction to fire classification and should not be confused with fire resistance.
Yes, RCM Multipurpose can be left permanently exposed providing all board edges and penetrations are suitably sealed, we would suggest using a sealing coat to maintain long term appearance.
Yes RCM Multipurpose can be used as a tile backer board.
Yes, 12mm thick RCM Multipurpose can be used with RCM Renderflex.
RCM Multipurpose edge distance is 12mm except at the board corners where fixings should be moved up or down to achieve 50mm. Fixings should be fixed using a maximum 600mm x 300mm grid pattern.
- 27 No. fixings per 2400mm x 1200mm sheet when fixed in a vertical orientation.
- 25 No. fixings per 2400mm x 1200mm sheet when fixed in a horizontal orientation.
- For fixing into SFS framing 4.8mm x 38mm self-drilling wingtip fixings suitably treated against corrosion should be used.
- For fixing into Timber framing 4.2mm x 42mm self-drilling fixings suitably treated against corrosion should be used.
RCM can supply Poly Crystalline Diamond (PCD) blades suitable for cutting RCM Multipurpose in a range of diameter and bore sizes, please contact RCM Technical department for further information.
Key Technical Certificates
Multipurpose Fact Sheet
